产品
-
快恢复二极管
Pb-free
AEC Qualified
Halide free
PPAP Capable
快速筛选
选择或筛选要查看的列
id
Product
Package
Description
Compliance
Datasheet
Marketing Status
Configuration
VRRM(V) max.
IF(A) max.
VF (V) max
IFSM(A) max.
IR(uA) max.
trr (ns) max
TJ(°C) max.
TJ(°C) min.
ECCN(US)
Processing...
| Id | Product | Package | Description | Compliance | DataSheet | Marketing Status | Configuration | VRRM(V) max. | IF(A) max. | VF (V) max | IFSM(A) max. | IR(uA) max. | trr (ns) max | TJ(°C) max. | TJ(°C) min. | ECCN(US) |
Id | Product | Package | Description | Compliance | DataSheet | Marketing Status | Configuration | VRRM(V)
max. | IF(A)
max. | VF
(V)
max | IFSM(A)
max. | IR(uA)
max. | trr
(ns)
max | TJ(°C)
max. | TJ(°C)
min. | ECCN(US) |
| R-1 | 1A,200V,35ns,Super Fast Rectifiers | Active | Single | 200 | 1 | 0.95 | 30 | 5 | 35 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,50V,150ns,Fast Recovery Rectifiers | Active | Single | 50 | 1 | 1.3 | 25 | 5 | 150 | 125 | -55 | EAR99 | ||||
| R-1 | 0.5A,1000V,300ns,Fast Recovery Rectifiers | Active | Single | 1000 | 0.5 | 1.8 | 25 | 5 | 300 | 125 | -55 | EAR99 | ||||
| R-1 | 0.5A,1200V,300ns,Fast Recovery Rectifiers | Active | Single | 1200 | 0.5 | 1.8 | 25 | 5 | 300 | 125 | -55 | EAR99 | ||||
| R-1 | 0.5A,1400V,300ns,Fast Recovery Rectifiers | Active | Single | 1400 | 0.5 | 1.8 | 25 | 5 | 300 | 125 | -55 | EAR99 | ||||
| R-1 | 0.5A,1500V,300ns,Fast Recovery Rectifiers | Active | Single | 1500 | 0.5 | 1.8 | 25 | 5 | 300 | 125 | -55 | EAR99 | ||||
| R-1 | 0.5A,1600V,300ns,Fast Recovery Rectifiers | Active | Single | 1600 | 0.5 | 1.8 | 25 | 5 | 300 | 125 | -55 | EAR99 | ||||
| R-1 | 0.5A,1800V,300ns,Fast Recovery Rectifiers | Active | Single | 1800 | 0.5 | 1.8 | 25 | 5 | 300 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,50V,150ns,Fast Recovery Rectifiers | Active | Single | 50 | 1 | 1.3 | 25 | 5 | 150 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,100V,150ns,Fast Recovery Rectifiers | Active | Single | 100 | 1 | 1.3 | 25 | 5 | 150 | 125 | -55 | EAR99 | ||||
| R-1 | 0.5A,2000V,300ns,Fast Recovery Rectifiers | Active | Single | 2000 | 0.5 | 1.8 | 25 | 5 | 300 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,100V,150ns,Fast Recovery Rectifiers | Active | Single | 100 | 1 | 1.3 | 25 | 5 | 150 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,200V,150ns,Fast Recovery Rectifiers | Active | Single | 200 | 1 | 1.3 | 25 | 5 | 150 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,200V,150ns,Fast Recovery Rectifiers | Active | Single | 200 | 1 | 1.3 | 25 | 5 | 150 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,400V,150ns,Fast Recovery Rectifiers | Active | Single | 400 | 1 | 1.3 | 25 | 5 | 150 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,400V,150ns,Fast Recovery Rectifiers | Active | Single | 400 | 1 | 1.3 | 25 | 5 | 150 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,600V,250ns,Fast Recovery Rectifiers | Active | Single | 600 | 1 | 1.3 | 25 | 5 | 250 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,600V,250ns,Fast Recovery Rectifiers | Active | Single | 600 | 1 | 1.3 | 25 | 5 | 250 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,800V,500ns,Fast Recovery Rectifiers | Active | Single | 800 | 1 | 1.3 | 25 | 5 | 500 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,800V,500ns,Fast Recovery Rectifiers | Active | Single | 800 | 1 | 1.3 | 25 | 5 | 500 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,1000V,500ns,Fast Recovery Rectifiers | Active | Single | 1000 | 1 | 1.3 | 25 | 5 | 500 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,1000V,500ns,Fast Recovery Rectifiers | Active | Single | 1000 | 1 | 1.3 | 25 | 5 | 500 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,50V,50ns,Ultra Fast Rectifiers | Active | Single | 50 | 1 | 1 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,50V,50ns,Ultra Fast Rectifiers | Active | Single | 50 | 1 | 1 | 30 | 5 | 50 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,100V,50ns,Ultra Fast Rectifiers | Active | Single | 100 | 1 | 1 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,100V,50ns,Ultra Fast Rectifiers | Active | Single | 100 | 1 | 1 | 30 | 5 | 50 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,200V,50ns,Ultra Fast Rectifiers | Active | Single | 200 | 1 | 1 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,200V,50ns,Ultra Fast Rectifiers | Active | Single | 200 | 1 | 1 | 30 | 5 | 50 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,300V,50ns,Ultra Fast Rectifiers | Active | Single | 300 | 1 | 1.3 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,300V,50ns,Ultra Fast Rectifiers | Active | Single | 300 | 1 | 1.3 | 30 | 5 | 50 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,400V,50ns,Ultra Fast Rectifiers | Active | Single | 400 | 1 | 1.3 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,400V,50ns,Ultra Fast Rectifiers | Active | Single | 400 | 1 | 1.3 | 30 | 5 | 50 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,600V,75ns,Ultra Fast Rectifiers | Active | Single | 600 | 1 | 1.7 | 30 | 5 | 75 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,600V,75ns,Ultra Fast Rectifiers | Active | Single | 600 | 1 | 1.7 | 30 | 5 | 75 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,800V,75ns,Ultra Fast Rectifiers | Active | Single | 800 | 1 | 1.7 | 30 | 5 | 75 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,800V,75ns,Ultra Fast Rectifiers | Active | Single | 800 | 1 | 1.7 | 30 | 5 | 75 | 150 | -55 | EAR99 | ||||
| R-1 | 1A,1000V,75ns,Ultra Fast Rectifiers | Active | Single | 1000 | 1 | 1.7 | 30 | 5 | 75 | 125 | -55 | EAR99 | ||||
| R-1 | 1A,1000V,75ns,Ultra Fast Rectifiers | Active | Single | 1000 | 1 | 1.7 | 30 | 5 | 75 | 150 | -55 | EAR99 | ||||
| DO-41 | 1A,50V,200ns,Fast Recovery Rectifiers | Active | Single | 50 | 1 | 1.3 | 30 | 5 | 200 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,50V,200ns, Fast Recovery Rectifiers | Active | Single | 50 | 1 | 1.3 | 30 | 5 | 200 | 150 | -55 | EAR99 | ||||
| DO-41 | 1A,100V,200ns,Fast Recovery Rectifiers | Active | Single | 100 | 1 | 1.3 | 30 | 5 | 200 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,100V,200ns,Fast Recovery Rectifiers | Active | Single | 100 | 1 | 1.3 | 30 | 5 | 200 | 150 | -55 | EAR99 | ||||
| DO-41 | 1A,200V,200ns,Fast Recovery Rectifiers | Active | Single | 200 | 1 | 1.3 | 30 | 5 | 200 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,200V,200ns,Fast Recovery Rectifiers | Active | Single | 200 | 1 | 1.3 | 30 | 5 | 200 | 150 | -55 | EAR99 | ||||
| DO-41 | 1A,400V,200ns,Fast Recovery Rectifiers | Active | Single | 400 | 1 | 1.3 | 30 | 5 | 200 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,400V,200ns,Fast Recovery Rectifiers | Active | Single | 400 | 1 | 1.3 | 30 | 5 | 200 | 150 | -55 | EAR99 | ||||
| DO-41 | 1A,600V,200ns,Fast Recovery Rectifiers | Active | Single | 600 | 1 | 1.3 | 30 | 5 | 200 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,600V,200ns,Fast Recovery Rectifiers | Active | Single | 600 | 1 | 1.3 | 30 | 5 | 200 | 150 | -55 | EAR99 | ||||
| DO-41 | 1A,400V,300ns,Fast Recovery Rectifiers | Active | Single | 400 | 1 | 1.3 | 30 | 5 | 300 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,600V,300ns,Fast Recovery Rectifiers | Active | Single | 600 | 1 | 1.3 | 30 | 5 | 300 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,1000V,300ns,Fast Recovery Rectifiers | Active | Single | 1000 | 1 | 1.3 | 30 | 5 | 300 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,800V,300ns,Fast Recovery Rectifiers | Active | Single | 800 | 1 | 1.3 | 30 | 5 | 300 | 125 | -55 | EAR99 | ||||
| TO-220AC | 30A,600V,Super Fast Rectifiers | Active | Single | 600 | 30 | 2.3 | 300 | 10 | 40 | 175 | -55 | EAR99 | ||||
| TO-263 | 30A,600V,Super Fast Rectifiers | Active | Single | 600 | 30 | 2.3 | 300 | 10 | 40 | 175 | -55 | EAR99 | ||||
| TO-263 | 30A,600V,Super Fast Rectifiers | Active | Single | 600 | 30 | 2.3 | 300 | 10 | 40 | 175 | -55 | EAR99 | ||||
| TO-263 | 30A,600V,Super Fast Rectifiers | Active | Single | 600 | 30 | 2.3 | 300 | 10 | 40 | 175 | -55 | EAR99 | ||||
| ITO-220AC | 30A,600V,Super Fast Rectifiers | Active | Single | 600 | 30 | 2.3 | 300 | 10 | 40 | 175 | -55 | EAR99 | ||||
| SMA | 1.5A,800V,120ns, Surface Mount Fast Recovery Rectifiers | Active | Single | 800 | 1.5 | 1.5 | 30 | 5 | 120 | 150 | -55 | EAR99 | ||||
| SMA | 1.5A,1000V,120ns, Surface Mount Fast Recovery Rectifiers | Active | Single | 1000 | 1 | 1.5 | 30 | 5 | 120 | 150 | -55 | EAR99 | ||||
| DO-41 | 1A,200V,35ns,Ultra Fast Rectifiers | Active | Single | 200 | 1 | 2.5 | 30 | 5 | 35 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,400V,35ns,Ultra Fast Rectifiers | Active | Single | 400 | 1 | 2.5 | 30 | 5 | 35 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,600V,35ns,Ultra Fast Rectifiers | Active | Single | 600 | 1 | 2.5 | 30 | 5 | 35 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,600V,35ns,Ultra Fast Rectifiers | Active | Single | 600 | 1 | 2.5 | 30 | 5 | 35 | 150 | -55 | EAR99 | ||||
| DO-41 | 1A,800V,75ns,Ultra Fast Rectifiers | Active | Single | 800 | 1 | 2.5 | 30 | 5 | 75 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,1000V,75ns,Ultra Fast Rectifiers | Active | Single | 1000 | 1 | 2.5 | 30 | 5 | 75 | 125 | -55 | EAR99 | ||||
| SOD-323HE | 1A,200V,35ns, Surface Mount Fast Recovery Rectifiers | Active | Single | 200 | 0.5 | 0.98 | 10 | 5 | 35 | 150 | -55 | EAR99 | ||||
| SOD-323HE | 1A,400V,35ns, Surface Mount Fast Recovery Rectifiers | Active | Single | 400 | 0.5 | 1.25 | 10 | 5 | 35 | 150 | -55 | EAR99 | ||||
| SOD-323HE | 1A,600V,35ns, Surface Mount Fast Recovery Rectifiers | Active | Single | 600 | 0.5 | 1.7 | 10 | 5 | 35 | 150 | -55 | EAR99 | ||||
| DO-41 | 1A,50V,50ns,Ultra Fast Rectifiers | Active | Single | 50 | 1 | 0.95 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,100V,50ns,Ultra Fast Rectifiers | Active | Single | 100 | 1 | 0.95 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,150V,50ns,Ultra Fast Rectifiers | Active | Single | 150 | 1 | 0.95 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,200V,50ns,Ultra Fast Rectifiers | Active | Single | 200 | 1 | 0.95 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,300V,50ns,Ultra Fast Rectifiers | Active | Single | 300 | 1 | 1.25 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,400V,50ns,Ultra Fast Rectifiers | Active | Single | 400 | 1 | 1.25 | 30 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-15 | 2A,50V,50ns,Ultra Fast Rectifiers | Active | Single | 50 | 2 | 0.95 | 75 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-15 | 2A,100V,50ns,Ultra Fast Rectifiers | Active | Single | 100 | 2 | 0.95 | 75 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-15 | 2A,150V,50ns,Ultra Fast Rectifiers | Active | Single | 150 | 2 | 0.95 | 75 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-15 | 2A,200V,50ns,Ultra Fast Rectifiers | Active | Single | 200 | 2 | 0.95 | 75 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-15 | 2A,300V,50ns,Ultra Fast Rectifiers | Active | Single | 300 | 2 | 1.25 | 75 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-15 | 2A,400V,50ns,Ultra Fast Rectifiers | Active | Single | 400 | 2 | 1.25 | 75 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-15 | 2A,600V,75ns,Ultra Fast Rectifiers | Active | Single | 600 | 2 | 1.7 | 75 | 5 | 75 | 125 | -55 | EAR99 | ||||
| DO-15 | 2A,800V,75ns,Ultra Fast Rectifiers | Active | Single | 800 | 2 | 1.7 | 75 | 5 | 75 | 125 | -55 | EAR99 | ||||
| DO-27 | 3A,50V,50ns,Ultra Fast Rectifiers | Active | Single | 50 | 3 | 0.95 | 125 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 3A,100V,50ns,Ultra Fast Rectifiers | Active | Single | 100 | 3 | 0.95 | 125 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 3A,150V,50ns,Ultra Fast Rectifiers | Active | Single | 150 | 3 | 0.95 | 125 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 3A,200V,50ns,Ultra Fast Rectifiers | Active | Single | 200 | 3 | 0.95 | 125 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 3A,300V,50ns,Ultra Fast Rectifiers | Active | Single | 300 | 3 | 1.25 | 125 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 3A,400V,50ns,Ultra Fast Rectifiers | Active | Single | 400 | 3 | 1.25 | 125 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 3A,600V,75ns,Ultra Fast Rectifiers | Active | Single | 600 | 3 | 1.7 | 125 | 5 | 75 | 125 | -55 | EAR99 | ||||
| DO-27 | 3A,800V,75ns,Ultra Fast Rectifiers | Active | Single | 800 | 3 | 1.7 | 125 | 5 | 75 | 125 | -55 | EAR99 | ||||
| DO-27 | 5A,50V,50ns,Ultra Fast Rectifiers | Active | Single | 50 | 5 | 0.95 | 150 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 5A,100V,50ns,Ultra Fast Rectifiers | Active | Single | 100 | 5 | 0.95 | 150 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 5A,150V,50ns,Ultra Fast Rectifiers | Active | Single | 150 | 5 | 0.95 | 150 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 5A,200V,50ns,Ultra Fast Rectifiers | Active | Single | 200 | 5 | 0.95 | 150 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 5A,300V,50ns,Ultra Fast Rectifiers | Active | Single | 300 | 5 | 1.25 | 150 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-27 | 5A,400V,50ns,Ultra Fast Rectifiers | Active | Single | 400 | 5 | 1.25 | 150 | 5 | 50 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,100V,35ns,Super Fast Rectifiers | Active | Single | 100 | 1 | 0.95 | 30 | 5 | 35 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,200V,35ns,Super Fast Rectifiers | Active | Single | 200 | 1 | 0.95 | 30 | 5 | 35 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,300V,35ns,Super Fast Rectifiers | Active | Single | 300 | 1 | 1.3 | 30 | 5 | 35 | 125 | -55 | EAR99 | ||||
| DO-41 | 1A,400V,35ns,Super Fast Rectifiers | Active | Single | 400 | 1 | 1.3 | 30 | 5 | 35 | 125 | -55 | EAR99 |
共 100 条数据
